Sophisticated machines and superb skills
Automatic Multi

Automatic Multi

Application: Power, liquid, cream and granule like sugar, coffee packed in a long narrow pouch. Packing for different ma;
Basic Info.
Model NO. MLP-04/MLP-06/MLP-08
Material Type Granule,Liquid,Powder
Packaging Stick Pouch, Pillow Pack
Packaging Material Film
Transport Package standard wodden case for export
Trademark Alpha-Pack
Origin Shenzhen, China
HS Code 8422400000
Production Capacity 500pieces/Year
Product Description
Application:
Power, liquid, cream and granule like sugar, coffee packed in a long narrow pouch. Packing for different materials can be accomplished by different dosing unit.
Standard Features:
1. The machine can automatically complete multi-lane products measuring, feeding, filling and bag forming, date code printing, bag sealing and cutting. And hole punching as option.
2. Motor driven heat seal film pulling system.
3. High sensitive fiber optic photo sensor can automatically trace color mark accurately.
4. PLC control system combined with touch screen, can easily set and change the packing parameters. Daily production output and self-diagnostic machine error can be viewed directly from the screen.
5. PID temperature controller monitors heat sealing temperature within ± 1º C
Optional Parts for Main Machine:
1. Date Code Printer
2. Straight Line Cut with easy tear
3. Hole punching device
4. Fix number bag cutting device
Model No. MLP-04-480MLP-06-480MLP-08-480
Bag Length (mm)70-20070-20070-200
Bag Width (mm)16-5016-3516-25
Film Width(mm)Max. 480Max. 480Max. 480
Lanes No. 468
Speed (Bag/min)120-180180-270240-360
Sealing FormatFin Seal or Envelope Seal

Automatic Multi-Lane Filling Sealing Packaging/Packing Machine for Sachet Bag Food/Powder/Water (MLP-04/MLP-06/MLP-08)

Automatic Multi-Lane Filling Sealing Packaging/Packing Machine for Sachet Bag Food/Powder/Water (MLP-04/MLP-06/MLP-08)

Automatic Multi-Lane Filling Sealing Packaging/Packing Machine for Sachet Bag Food/Powder/Water (MLP-04/MLP-06/MLP-08)

Automatic Multi-Lane Filling Sealing Packaging/Packing Machine for Sachet Bag Food/Powder/Water (MLP-04/MLP-06/MLP-08)

Automatic Multi-Lane Filling Sealing Packaging/Packing Machine for Sachet Bag Food/Powder/Water (MLP-04/MLP-06/MLP-08)
